X-Rite Judge QC
Light Booth (Box) for Entry-level Visual Assessment
Light sources: Daylight D65 or D50, TL84, Cool White (CWF), UVA, CIE A, and one of TL84, U30, U35
Our Amazing Clients！
Economical Light Booth to Deploy Across Supply Chains
Integrating a light booth into a color evaluation workflow improves quality control, reduces waste due to rejects and rework, shortens time to market, and improves overall product quality. The durable and compact X-Rite Judge QC light booth offers an economical way to evaluate color quality and identify color errors earlier in the process for a rapid ROI.
5 Light Sources, including optional LED
- Offers 5 light sources including optional LED for visual assessment
- Built to last with industrial construction
- Provides economical color evaluation for a global supply chain
Visually evaluating color under multiple light sources can help detect color defects and metamerism. The Judge QC light booth offers five light sources including 2 Class B daylight options (D50 or D65), Cool White Fluorescent, Incandescent A, Ultraviolet, one of TL84 or U30, and the option of Cool White Fluorescent or an LED light source (L940 or L950) to evaluate color with confidence.
Economical and Durable
The Judge QC is a compact and easy-to-use controlled lighting solution that removes subjectivity from color assessment. With a Dual Daylight mode, it enables users to easily switch between the D50 light source for print and packaging and D65 for industrial applications. It also comes fully equipped with a UVA lamp for accurate evaluation when samples contain optical brightening agents (OBAs) to achieve a “whiter-than-white” effect on a range of materials, including plastics, paints and coatings and paper.
Best-in-Class Global Service and Support
X-Rite has been helping customers master color quality for 60+ years. With global service centers and 40+ certified service partners, our comprehensive support includes technical assistance, ISO certification, Service Care Plans, training, and more. Whether troubleshooting issues, optimizing workflows, or staying current with the latest technology, you can trust our service and support teams to provide prompt and reliable assistance to minimize disruptions.
Standards Compliance
The Judge QC light booth complies with the following industry standards: ISO, ASTM, AATCC, and BSI visual assessment requirements.
Ensures Maximum Up-Time
Designed for convenience and maximum up-time, this light booth includes multiple lamp replacement options and an indicator light when service is needed.
Compact for Smaller Samples
The Judge QC offers a compact internal viewing area that measures D18.5 x H15 x W25 in. (D47 x H38 x W63.5 cm.)
Applications
Textiles, clothing, dyeing, printing, plastics, pigments, paints, inks, coatings, photography, and more industries that need accurate colors.
Specifications
| Brand | X-Rite |
| Model | Judge QC |
| Calibration | No |
| Communication Interface | Touchpad |
| Dimensions (length, width, height) | D 21.1 in x W 27.0 in x H 21.4 in / D 53.5 cm x W 68.5 cm x H 54.5 cm |
| Humidity | Rh 0 to 95% max (non-condensing) |
| Industry Standards | ISO, ASTM, AATCC, and BSI visual assessment requirements |
| Instrument Display | Indicator Light |
| Internal Temperature & Humidity Sensor | No |
| Lamp Life | 2000hrs |
| Lamp Timer | Yes |
| Languages Supported | English |
Light Level Adjustment | N/A |
| Light Level Sensor | N/A |
| Light Source | D50 or D65, CWF, UVA, CIE A, and one of TL84, U30, U35 |
| Material | Steel |
| Operating Temperature Range | 32°F to 104°F / 0°C to 40°C |
| Safety | ETL Listed |
| Service Indicator | Yes |
| Shipped Weight | 70 lbs / 31.5 kg |
| Storage Temperature Range | 32°F to 104°F / 0°C to 40°C |
| Total Light Sources | 5 |
| Unit Color | Munsell N7 |
| UV Metamerism Index | Grade C ( AS DEFINED BY CIE 51.2-1999 TECHNICAL REPORT, “A METHOD FOR ASSESSING THE QUALITY OF DAYLIGHT SIMULATORS FOR COLORIMETRY.” ) |
| Viewing Area (depth, width, height) | 25 in x 18.5 in x 15 in / 63.5 cm x 47 cm x 38 cm |
| Visible Metamerism Index | Grade B ( AS DEFINED BY CIE 51.2-1999 TECHNICAL REPORT, “A METHOD FOR ASSESSING THE QUALITY OF DAYLIGHT SIMULATORS FOR COLORIMETRY.” ) |
| Voltage | 100, 115, 127, 230V |
| Warm Up Time | 3min (flourescent) |
| Warranty | 1-2 year |
| Wattage | 65W Max. |
| Weight | 60 lbs / 27 kg |
Light sources description:
D65 – International standard Artificial Daylight, color temperature is 6500K. CIR is 98. Specified for most applications where color consistency and quality are required. High conformance to ISO 23603 – CIE S 012/E specifications for accurate color matching.
D50 – Color Proof “Artificial Daylight”for graphic and photographic applications., color temperature is 5000K. CIR is 98.
TL84 – Applicable for stores in China, Japan and Europe, color temperature is 4000K,CIR is 85.
CWF – (Cool White Fluorescent) American Standard, color temperature is 4150K, CIR is 62. TL83 – ( Warm White Fluorescent ), American Standard, color temperature is 3000K, CIR is 85
U35 – One of an American light source , color temperature 3500K. CIR is 85
F – “Sun-setting Light Yellow” incandescent light source (imitation of sunset), Required by BS 950: Part 1 as a test for metamerism (approximating CIE Illuminant ‘A’ ) color temperature 2700K. CIR is 100
A – Tungsten Halogen Lighting (CIE Illuminant ‘A’ ). This represents incandescent A (inc-A) with a colour temperature of 2856K. CIR is 100 Typical light source used to check for metamerism.
UV– Ultraviolet Blacklight. Used to detect the presence of Optical Brightening Agents or Fluorescent dyes. Therefore it is useful when assessing white and Fluorescent shades to check the level present and its evenness.
D75 – International standard Artificial Daylight, color temperature is 7500K,CIR is 96. High CIE specifications for accurate color matching.
LED – GE LED11ET8/G/2/940: 4000K, CRI 90+
Frequently Asked Questions
How to choose a light booth?
Choose the same as your customers, it is essential to have consistent light sources.
Do you have the 6500K light booth?
Yes, we have it. A 6500K light booth refers to a light booth with daylight D65 light sources, providing a color temperature of 6500K.
What should I be careful about when using it?
No, simply place it on a table for use.
What if the product gets damaged during transportation?
We will arrange a replacement shipment at our expense.
When to replace light tubes? How to buy?
After 2000 hours of use or if there are any issues. Contact us and for faster service, please send us a photo of one of the end of the light tube with the printed markings.
Can it be customized?
Yes, customization is available. OEM & ODM too.
Why do i need a light booth?
Colors can look different under different light sources. For example, the same color may appear slightly different on a cloudy day, during rainy weather, indoors, outdoors, or under different lighting conditions used by different clients. This raises the question of which light source should be considered as the standard reference. However, a color light booth can help solve this issue.
Metamerism is an optical phenomenon where two colors may seem to match under one light source but appear different under another light source. It’s like when you have a shirt that appears perfectly matched under one type of lighting, but when you step outside or view it under a different light, it suddenly appears to be a slightly different color. Metamerism can pose challenges in maintaining color consistency and achieving accurate color representation across various lighting conditions. By using a light booth, you can identify and address any metameric effects, ensuring consistent and reliable color evaluation.
Vteke light booths are known by various names, such as light boxes, viewing booths, color assessment cabinets, color matching booths, and more. Contact us to find the right one for your needs.
